Multi channel amplifier

digiBOX industrial

Name: digiBOX industrial
Brand: Anwit
SKU: 3636
Price: 1.00 UAH
Availability: PreOrder

Intelligent Strain Gauge and Charge Amplifier with IT/OT Connectivity

Robust and configurable multichannel amplifier featuring process algorithms for industrial applications.

Intelligent Edge-Amplifier with IT/OT connectivity

Overview

Downloads

CHARACTERISTIC FEATURES

Connection of strain gauge and piezoelectric sensors (freely configurable 2-4 channels)
40kS/s sampling rate per strain gauge and piezo channel with 24-bit A/D conversion
Sample synchronous data acquisition for strain-gauge and piezoelectric channels
Robust and compact metal housing (IP67)
4 digital I/Os and 4 analog outputs (voltage/current switchable)
Simple operation via integrated web server
Internal calculation channels (statistical functions)
PROFINET (IRT/RT 2KHz, 4KHz), EtherCAT® (daisy-chain topology possible)
Parallel IT-level connection: TCP/IP-based protocols: openDAQ, MQTT, OPENAPI (RestAPI)

File	Language
digiBOX Industrial - Data Sheet (B06193)	English

Sensor input

Signal processing

IT/OT Connectivity

Sensing Technology

digiBOX Industrial can be freely configured with (2-4) inputs for both strain gauge based and piezoelectric sensors. HBK provides a range of sensors for both sensing technologies that measure: Strain, Force, Load, Torque, Pressure.
The sensor inputs are synchronized sample synchronous, enabling challenging industrial measurements with a 40 kS/s sample rate and 24-bit AD conversion for both input technologies.

Signal Processing

digiBOX Industrial features integrated statistical functions developed for industrial measurement applications: 4x Min, Max, and peak-to-peak tracking; 4x capture values; 8x limit switches;
These values are calculated every 25 µs. This enables the execution of complex and demanding process control applications leveraging the digiBOX as decentralized process controller.

Additionally, the digiBOX features an intuitive webserver which is used to configure and parametrize the device. This allows for an efficient system setup and servicing of the digiBOX.

IT/OT Connectivity

digiBOX Industrial offers parallel IT/OT connectivity ensuring seamless integration with a machine's PLC system while simultaneously making measurement data, calculated results and device parametrisation accessible to IT-level applications without compromising the ongoing PLC process.

This provides the IT-Level with critical process data from force measurement processes, enabling new possibilities such

historical data storage and tracking;
complex monitoring;
data acquisition (miniDAQ) and analysis;
building machine learning models;
digital twin applications;
Remote access and cloud integration;
These capabilities are easily implemented using the integrated openDAQ™ protocol, which allows for streaming 40 kS/s sensor data and seamless integration into programming environments based on Python, C# and C++.

IT-Level connectivity allows for new solutions

Downloads

digiBOX Industrial - Data Sheet (B06193)
