Amplifier modules

8 channel DC amplifier ML801B

Name: 8 channel DC amplifier ML801B
Brand: Anwit
SKU: 4562
Price: 1.00 UAH
Availability: PreOrder

Multi-channel amplifier with 8 channels for acquisition of physical quantities like voltages, current, temperature and strain (full, half, quarter bridge)
TEDS Transducer identification
Accuracy class: >= 0,05
Automatic tare
2 peak-value memories per channel
Low-pass filter
Calibration signal

Specification

Accessories

Number of inputs	8
Input	Electrical voltage, Electrical current, Strain gauge full/half bridge, Strain gauge quarter bridge, IEPE / CCLD, Piezo resistive bridge, Thermocouples, Resistance (PTC, NTC, KTY)
Output	None
Interface	TCP/IP
Accuracy class	0.05, 0.1, 1
Degree of protection	IP20
Sample rate [S/s]	2.4 kHz
Real-time capabilities	None

Product Code	Description
1-AP402I	Connection board, for 4 sockets Lemo
1-AP809	Connection board for 8 thermocouples
1-AP801S6	Connection board for 8 voltages, Lemo
1-AP810I	Connection board for 8 full/half bridges
1-AP814BI	Connection board 8 quarter bridges 3wire
1-AP418I	Connection board for 4 piezo-transducers
1-AP815I	Connection board for 8 SG bridges
1-AP836I	Connection board for 8 potentiometers
1-AP801	Connection board with 8 ±10 V inputs
1-AP835	Connection board for 8 Pt100, Lemo

Downloads

MGCplus - Data Sheet (B00554)
